Attention! The transmitter and receiver must be set to the same transmission rate
The setting of the Baud rate effects the communication of the modules CM-232 and
CM-485. The KP232 interface adapter adjusts the Baud rate automatically to the PC
or control transmission rate.
Work steps:
•
•
•
•
•
Protocol type settings
By default, the communication modules CM-232/CM-485 are set to the BONFIGLIOLI
VECTRON standard protocol (VCB-Bus). Communication with the VPlus control soft-
ware is only possible with this protocol type.
Attention! If another protocol type or a wrong setting is selected, no communica-
Note:
05/08
05/08
(Baud rate).
Install module CM-232/CM-485 on the frequency inverter.
In the case of module CM-232:
Connect CM-232 and PC/PLC via RS232 cable.
In the case of module CM-485:
Connect CM-485 via RS485 cable with interface converter.
Connect the RS232 port of the interface converter with the PC/PLC.
Plug in control unit KP500 or interface adapter KP232 to slot A of the frequency
inverter.
In the case of KP232: Connect interface adapter KP232 to PC via a serial cable.
tion is possible via CM-232/CM-485.
In this case, correct the protocol type using the control unit KP500.
For detailed information, see chapter 6 "Modbus over Serial Line Proto-
col".
The interface adapter KP232 operates with the BONFIGLIOLI VECTRON
standard protocol VCB-Bus independent of the communication module
CM-232 or CM-485 and can communicate with VPlus at any time.
