Startup; General Information On Configuration - BONFIGLIOLI Vectron ACTIVE Manual

5
By default, the parameters of the communication modules CM-232 and CM-485 are
set as follows:
1375 Modbus Parity
1376 Modbus Address
5.1
The CM-232 / CM-485 communication modules can be configured in different ways:
Attention!
14
14

Startup

Parameter
No. Description
395 Protocol Type
413 Watchdog Timer
Parameter
No. Description
10 Baud Rate

General Information on configuration

− Direct connection CM-232 to PC / PLC
Direct connection between the 9-pin Sub-D socket (X310) of the
CM-232 and the serial interface of a PC / PLC.
Configuration of the installed communication module via the control
software VPlus or the control unit KP500.
In the case of the CM-232 the connection to a PC / PLC is realized
via a RS232 connection cable (1:1).
− Direct connection CM-485 to PC / PLC
Direct connection between the 9-pin Sub-D socket (X310) of the
CM-485 and the serial interface of a PC via an interface converter.
For connection of the CM-485 to the RS232 interface of the PC /
PLC, an appropriate interface converter must be installed in the sig-
nal line.
Configuration of the installed communication module via the control
software VPlus or the control unit KP500.
− Connection of interface adapter KP232 to PC
Connection of the interface adapter KP232 at slot A of the fre-
quency inverter. Connection to PC via a RS232 connection cable
(1:1). Configuration of the installed communication module via the
control software VPlus.
− Configuration via Control Unit KP500
Configuration via the pluggable control unit KP500 at slot A of the
frequency inverter.
Modbus Instruction manual
Modbus Instruction manual
Settings
Factory setting
0 - VCB bus protocol
0
Settings
Factory setting
4 - 19200
0 – EVEN
1
05/08
05/08
