After mains on (Reset), the inverter is in the state "Starting lock-out" (0x40).
With transitions 4 and 5, there is a change between "Operation released" (0x27, out-
put stages released, drive working) and "Switched on" (0x23, output stages disabled).
The release (transition 4) is only possible if the controller release signal and the corre-
sponding control command are present at digital external release AND (S2IND OR
S3IND). They can be firmly wired or also firmly linked to the logic states On or Off via
the configuration of the digital inputs. If the control signal at the external release is
withdrawn, the output stages can be disabled at any time. The drive then coasts to a
standstill. In this case, there is a transition to "Switched on" (0x23, output stages dis-
abled).
Note:
The behavior of Transition 5 can be set via parameter
you can use coasting, shut-off via ramp (reversible) or DC braking (depending on the
selected configuration, see Chapter 9.1.2.2, "
Parameter
meaning:
54
54
External release has top priority for the controller release and is to be
hard-wired.
Control Word
410 has a length of 16 bits. The set bits have the following
Control Word
Bit no. Function / name
Switch on
0
Voltage - disable
1
Quick stop
2
Operation - released
3
4 –
–
5
–
6
Reset fault
7
8 –
–
9
–
10
11 –
–
12
–
13
–
14
–
15
Modbus Instruction manual
Modbus Instruction manual
Behavior in state-transition 5").
410
state-transition 5
392. Here,
