Note:
82
82
Code
F07 00 DC link voltage too high, check deceleration ramps and connected brake
Resistor.
DC link voltage too low, check mains voltage.
01
Power failure, check mains voltage and circuit.
02
Phase failure, check mains fuses and circuit.
03
Reference DC-Link Limitation
04
Brake chopper
05
Motor chopper
06
Code
F08 Electronics voltage 24 V too low, check control terminal.
01
Electronics voltage too high, check wiring of control terminals.
04
Code
F11 Output frequency too high, check control signals and settings.
00
Max. frequency reached by control, check deceleration ramps and
01
connected brake resistor.
Code
F13 00 Earth fault on output, check motor and wiring.
IDC Compensation Limit
Set
01
increase limit, if necessary.
Minimum current monitoring, check motor and wiring.
10
Code
F14 Reference value on multifunctional input 1 faulty, check signal.
01
Overcurrent on multifunctional input 1, check signal.
07
Speed sensor signal defective, check connections S4IND and S5IND.
30
One track of the speed sensor signal is missing, check connections.
31
Direction of rotation of speed sensor wrong, check connections.
32
Code
F20 10 Communication watchdog RS232/RS485.
In addition to fault messages mentioned, there are further fault mes-
sages. However these messages are only used for internal purposes and
are not listed here. If you receive fault messages which are not listed
here, please contact us !
Modbus Instruction manual
Modbus Instruction manual
DC link voltage
Meaning
680 too low, check mains voltage.
Trigger Threshold
506 too low, check mains voltage.
Trigger Threshold
507 too low, check mains voltage.
Electronics voltage
Meaning
Output frequency
Meaning
Motor Connection
Meaning
415 reached, check motor and cabling,
Control Connection
Meaning
Communication
Meaning
