Note:
The reference values can be read out on the frequency inverter with the help of the
KP500 control unit or VPlus operating software.
Internal reference fre-
quency
Reference bus frequency
282
Reference ramp fre-
quency
05/08
05/08
Ramp set-point
If 434 = 2 (only reference line value), this reference line
value is limited to fmin. Please consider that the sign in front of fmin at
reference value = 0 is derived from the sign in front of the last reference
line value ≠ 0.
After Power On, the reference line value is limited to +fmin!
Ramp set-point
For
value results from the sum of internal reference frequency value
and reference line value.
Parameter
Internal reference value from frequency ref-
erence value channel
228
Reference line value.
Sum of internal + reference line value
283
Modbus Instruction manual
Modbus Instruction manual
434 = 3, the sign in front of the overall reference
Actual values
Contents Format
xxx.xx Hz
xxx.xx Hz
xxx.xx Hz
