CEA DIGITECH vision PULSE 3200 Operator's Manual page 67

Error
Error code
condition
Err E0.1
Err E0.2
Err E0.3
Err E0.4
Err E0.5
Err E0.6
Err E0.7
Err E0.8
Err E0.9
Err T°C
Err H20
Err E1.0
Err E1.1
Err E1.2
OVER AND UNDER VOLTAGE
Automatic reset error.
OVER VOLTAGE
Automatic reset error.
UNDER VOLTAGE
Automatic reset error.
OVER CURRENT
Automatic reset error.
REMOTE COMMANDS
No feed for remote commands.
NON automatic reset error.
WATER COOLER MISSING
NON automatic reset error.
Check that the WATER COOLER SYSTEM - OBLIGATORY function is included within the
ADVANCED SETUP Menu / EQUIPMENT LAYOUT.
After this initial check you need to know that this error can only occur in the following cases:
• Water cooler system not connected to the welding machine.
• The welding machine does not recognise the water cooler system, even though it is connected
correctly.
• Water cooler system disconnected when the machine is operating normally.
Once the water cooler system has been reactivated, this error condition resets itself
automatically!
If the alarm occurs even when the WATER COOLER SYSTEM - OPTIONAL function is included in
the ADVANCED SETUP Menu / EQUIPMENT LAYOUT, call Technical Assistance Department
immediately.
MOTOR FAULT
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
WIRE FEEDER MISSING
NON automatic reset error.
Check that the WIRE FEEDER - OBLIGATORY function is included within the ADVANCED SETUP
Menu / EQUIPMENT LAYOUT.
After this initial check you need to know that this error can only occur in the following cases:
• Wire feeder not connected to the welding machine.
• The welding machine does not recognise the wire feeder, even though it is connected correctly.
• Wire feeder disconnected when the machine is operating normally.
Once the wire feeder has been reactivated, this error condition resets itself automatically!
If the alarm occurs even when the WIRE FEEDER - OPTIONAL function is included in the
ADVANCED SETUP Menu / EQUIPMENT LAYOUT, call Technical Assistance Department
immediately.
CAN INTERNAL ERROR
Faulty communication between the generator and the feeder.
NON automatic reset error.
Error visible on VISION S
CREEN
THERMAL PROTECTION
The welding stops due to an excessively high temperature (thermostat activated).
Automatic reset error.
COOLER PRESSURE
The fluid in the cooling system is at low pressure.
NON automatic reset error.
CONFIG. FILE MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
USER FILE MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
TORCH FILE MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
Error description and possible diagnosis
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
48
(continued)
