1 - PROGRAM SELECTION Menu (PROGRAM)

To access the PROGRAM SELECTION Menu (PROGRAM) push the MENU K
ENCODER K
MENU K
EY
ENCODER K - SX
NOB
ENTER/MEM K
EY
It is not possible to access the PROGRAM SELECTION Menu (PROGRAM) via the HT5 control panel.

2 - WELDING MODE SELECTION Menu (MODE)

To access the WELDING MODE SELECTION Menu (MODE) push the MENU K
ENCODER K
MENU K
EY
ENCODER K - SX
NOB
ENTER/MEM K
EY
"DH" / "VS" CONTROL PANEL
MENU K
EY
- SX
NOB
Used to access subsequent menus if there are any.
Select the welding program.
Used to access PRE-SETTING of the program selected.
"HT5" CONTROL PANEL (not used with DH 32 and VS 32)
"DH" / "VS" CONTROL PANEL
MENU K
EY
- SX
NOB
Used to access subsequent menus if there are any.
Select the welding mode.
Used to access the PRE-SETTING for the program selected beforehand, in the MODE
chosen.
.
EY
PRG MATERIAL Ø GAS
1011 Fe G3 SI-1 0.8 Ar 16-20% CO2
1012 Fe G3 SI-1 1.0 Ar 16-20% CO2
1013 Fe G3 SI-1 1.2 Ar 16-20% CO2
1014 Fe G3 SI-1 1.6 Ar 16-20% CO2
1021 Fe G3 SI-1 0.8 Ar 11-15% CO2
1/50
1011 Fe G3 SI-1 Ø 0.8 Ar 16-20% CO2
EY
TWO STROKE (2T)
FOUR STROKE (4T)
CRATER 2T
CRATER 4T
SPOT WELDING
STITCH WELDING
1011 Fe G3 SI-1 Ø 0.8 Ar 16-20% CO2
8
ENTER/MEM K
EY
.
ENTER/MEM K
EY
