ERROR LOG

The purpose of this menu is to allow the operator to know, interpret, and understand error conditions that have occurred or may
be encountered on the welding plant.
To access the ERROR LOG Menu from the SETUP Menu:
• Turn the ENCODER K
NOB
• Push the ENTER/MEM K
EY
ENCODER K
Within the menu the following is indicated for each individual error:
• Its code (e.g. E1.0).
• A short description (e.g. no configuration file).
• The number of times this has occurred since the last time the machine was switched on (Curr).
• The number of times this has occurred since the last ALARM COUNTER RESET or TOTAL RESET (Tot.) of the welding machine.
• Errors that have occurred on the welding plant and subsequently been corrected, but not yet partially reset, are highlighted in
yellow.
• Errors that have occurred on the welding machine, but that have not yet been resolved and so are still active, are highlighted
in red.
ERRORS Curr. Tot.
E0.1 OVER AND UNDER VOLTAGE 0 0
E0.2 OVER VOLTAGE 0 0
E0.3 UNDER VOLTAGE 0 0
E0.4 OVER CURRENT 0 0
E0.5 REMOTE COMMANDS 0 0
E0.6 WATER COOLER MISSING 1 6
Within the menu, by rotating the ENCODER K
and select them.
Error
Error code
condition
Err E0.0
This indicates the gateway number to which the welding machine has been assigned.
- SX to select the desired icon.
.
MENU K
EY
SX K
EY
- SX
NOB
RESET Curr (RESET PARTIAL ERROR COUNT)
The counter that indicates how many times a error or alarm has occurred since the last time the
machine was switched on is part of this menu, and can be zeroed as follows:
• Choose the error for which the partial counter (Curr) must be reset by rotating the SX - ENCODER K
• The VISION S
displays an icon in the bottom right corner (see image) that indicates that you can
CREEN
proceed with resetting.
• Hold down the DX K until resetting of the (Curr) counter has been completed.
EY
- SX it is possible to scroll the errors (also indicated in the table below), view them
NOB
POWER SUPPLY FAILURE
NON automatic reset error.
This error can only arise when switching on and not when the welding plant is working normally.
Error visible on VISION S
Description
ERRORS Curr. Tot.
E0.5 REMOTE COMMANDS 0 0
E0.6 WATER COOLER MISSING 1 5
E0.7 MOTOR SPEED 0 0
E0.8 WIRE FEEDER MISSING 0 0
T°C THERMAL PROTECTION 0 0
E7.0 RC ANALOGIC MISSING 1 2
Error description and possible diagnosis
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
CREEN
