Pre-Setting - CEA DIGITECH vision PULSE 3200 Operator's Manual

The SPECIAL FUNCTIONS (Fx) related to the TIG LIFT process correspond as follows to those on the wire feeder:
Special function
UP SLOPE
DOWN SLOPE
TIG PULSE DELTA CURRENT
TIG PULSE BALANCE
TIG PULSE FREQUENCY
SWS VOLTAGE THRESHOLD
WARNING:
• It is possible to access editing of the SPECIAL FUNCTIONS (Fx) during welding.
• Some of the values edited will be used immediately by the operator, while others will be active from when the next welding
task begins.
• The HOLD function is not active within the SPECIAL FUNCTIONS Menu (SET UP Fx).

2 - PRE-SETTING

ENCODER K
MENU K
EY
ENCODER K - SX
NOB
PARAMETER DISPLAY S
PARAMETER SELECTION LED - A
PARAMETER DISPLAY S
CREEN
PARAMETER SELECTION LED - A
PARAMETER DISPLAY Screen - A
F29
F30
F23
F25
F26
F31
"DH" / "VS" CONTROL PANEL
MENU K
EY
- SX
NOB
Used to access the PROCESS SELECTION Menu (PROCESS) and subsequent menus, as
applicable.
Adjust the value of the parameter WELDING CURRENT ( ).
"HT5" CONTROL PANEL (not used with DH 32 and VS 32)
- A
CREEN
ENCODER K - A
NOB
- A
Displays the value of the parameter WELDING CURRENT ( ).
The LED unit shows the WELDING CURRENT ( ) switched on.
Default
0.0s
2.0s
-50%
0
100.0Hz
0
A V
111 50.0
24
PARAMETER DISPLAY Screen - V
Range
(0.0 - 5.0)s
(0.0 - 8.0)s
(-100 ÷ 1000)%
(-40 ÷ 40)%
(0.1 ÷ 500.0)Hz
-30 - +30
PARAMETER DISPLAY S
CREEN
PARAMETER SELECTION LED - V
TIG LIFT
- V
(continued)
