JOB EDIT

The purpose of this menu is to allow the operator to copy or delete a JOB (automatic welding point) entered previously.
To access the JOB EDIT Menu from the SETUP Menu:
• Turn the ENCODER K
NOB
• Push the ENTER/MEM K
EY
ENCODER K
PRG JOB PROCESS I
001 MMA 97
002 0011 MIG/MAG SYNERGIC 211
003 MMA 97
004 --- --- ---
005 --- --- ---
006 --- --- ---
COPY JOB 002
PRG JOB PROCESS I
001 MMA 97
002 0011 MIG/MAG SYNERGIC 211
003 MMA 97
004 0011 MIG/MAG SYNERGIC 211
005 --- --- ---
006 --- --- ---
DELETE JOB 004?
To exit the JOB EDIT Menu and go back to the SETUP Menu:
• Push the MENU K
.
EY
- SX to select the desired icon.
.
MENU K
EY
SX K
EY
- SX
NOB
COPYING THE JOB SELECTED
To copy the JOB selected, proceed as follows:
• Select the JOB to be copied by rotating the ENCODER K
• Push the SX K
.
EY
• Choose the position to which the JOB selected is to be copied (or overwritten *) by rotating the
ENCODER K - SX.
NOB
• Push the ENTER/MEM K
EY
* In the case of overwriting, confirmation will be requested.
DELETING THE JOB SELECTED
To delete the JOB selected, proceed as follows:
• Select the JOB to be deleted by rotating the ENCODER K
• Push the DX K
.
EY
• Push the SX K
to confirm and finalise deletion of the JOB selected.
EY
• To cancel the operation of deleting the JOB selected, push the DX K
PRG JOB PROCESS I
001 MMA 97
002 0011 MIG/MAG SYNERGIC 211
003 MMA 97
004 --- --- ---
005 --- --- ---
006 --- --- ---
to confirm and finalise copying of the JOB selected.
36
ENTER/MEM K
EY
DX K
EY
ENCODER K - DX
NOB
VISION S
CREEN
- SX.
NOB
- SX.
NOB
.
EY
