5 - HOLD

MMA
When welding ends the fields in the display must show the same values that were displayed during welding, with the difference
that they are now values defined as HOLD. In this phase the VISION S shows the HOLD box highlighted, while on the HT5
CREEN
panel the HOLD F LED flashes until the end of the HOLD Function. If the HOLD Function is Interrupted via a panel (e.g. DH),
UNCTION
it will also be interrupted automatically on the other (HT5) and vice-versa.
"DH" / "VS" CONTROL PANEL
HOLD
A V
68 7.2
PROGRAM 3200
MMA Cr Ni
"HT5" CONTROL PANEL (not used with DH 32 and VS 32)
HOLD Function LED
21
