Error
Error code
condition
Err E1.3
Err E1.6
Err E1.7
Err E1.8
Err E1.9
Err E2.0
Err E3.2
Err E3.3
Err E4.0
Err E4.1
Err E4.2
Err E4.3
Err E4.4
Err E4.5
CALIBRATION FILE MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
MMA DEFAULTS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
TIG DEFAULTS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
MIG DEFAULTS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
WELDER DEFAULTS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
FILE SYSTEM ERROR
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
STICKING
This error is displayed when a short-circuit has been formed between the machine's output
terminals for more than 1.2 seconds.
NON automatic reset error.
To remove the error state, eliminate the short circuit so that the voltage on the torch goes above the
threshold value again. At this stage the error condition disappears and the welding machine goes
back to the mode prior to the sticking. If the torch trigger is still pushed, it must be released and
pressed again to begin welding again.
MOTOR SPEED FAULT
NON automatic reset error.
Check that the rollers on the wire feeder mechanism are not stuck and that the welding wire comes
out correctly, otherwise contact Technical Assistance Department immediately.
LAST SETUP NOT VALID
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
JOBS WRONG
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
MIG SYN SPECIAL FUNCTION (Fx) WRONG
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
MIG MAN SPECIAL FUNCTION (Fx) WRONG
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
SPECIAL PULSED MIG FUNCTIONS (Fx) NOT VALID
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
SPECIAL DOUBLE PULSED MIG FUNCTIONS (Fx) NOT VALID
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN
Error description and possible diagnosis
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
ONLY in the event of a fault and NOT in the ERROR LOG Menu.
49
(continued)
