The contents of thus menu are for information only, the operator cannot change anything they can only read the information con-
tained by scrolling the various options available in the menu by rotating the ENCODER K
To exit the INFO Menu and go back to the SETUP Menu:
• Push the MENU K .
EY

NETWORK

This menu is used to view the settings for the Ethernet network if connected. If not, the following image is displayed:
Function
LINK STATUS
LINK STATUS NOT ACTIVE
CONFIGURATION DHCP
IP ADDRESS 169.254.136.178
NETMASK 255.255.0.0
GATEWAY 0.0.0.0
Digitech Vision 5000 [FX00204904080100]
CONFIGURATION
LINK STATUS NOT ACTIVE
CONFIGURATION DHCP
IP ADDRESS 169.254.136.178
NETMASK 255.255.0.0
GATEWAY 0.0.0.0
Digitech Vision 5000 [FX00204904080100]
IP ADDRESS
LINK STATUS NOT ACTIVE
CONFIGURATION DHCP
IP ADDRESS 169.254.136.178
NETMASK 255.255.0.0
GATEWAY 0.0.0.0
Digitech Vision 5000 [FX00204904080100]
NETMASK
LINK STATUS NOT ACTIVE
CONFIGURATION DHCP
IP ADDRESS 169.254.136.178
NETMASK 255.255.0.0
GATEWAY 0.0.0.0
Digitech Vision 5000 [FX00204904080100]
The special programs enabled, specifically:
• PULSED
• ECP estended curves package
• VISION.COLD
• VISION.PIPE
• VISION.POWER
• VISION.ULTRASPEED
LINK STATUS NOT ACTIVE
CONFIGURATION DHCP
IP ADDRESS
NETMASK
GATEWAY
Digitech Vision 5000 [FX00204904080100]
This indicates that the welding machine has an active connection to the Ethernet
network.
This indicates the type of network configuration used.
The DHCP protocol is obligatory.
This indicates the IP address to which the welding machine has been assigned.
This indicates the sub-network template number to which the welding machine has been
assigned.
46
