Appendix C– Pinouts
This appendix describes the pinouts for the AHIP6+ connectors defined in Chapter 2.

VGA Connector (VGA1)

C-1
Pin Signal
1 RED
2 GREEN
3 BLUE
4 NC
5 ORB_GND
6 ORB_GND
7 ORB_GND
8 ORB_GND
9 Fused VCC
10 ORB_GND
11 NC
12 DDCDAT
13 HSYNC
14 VSYNC
15 DDCCLK
NC = no connect
