3408/3410/3412 Series Industrial PC System Manual
Command Description
Edit Displays a graphic representation of the keypad in memory and a menu bar displaying
Exit, Click, and ON/OFF. Exit returns to the Macros menu. Click is not supported. To
select a key to edit, use the arrow keys to position the cursor on the desired key and
press
In edit mode, the macro is displayed as two lines. The top line (the edit line) displays
the macro in either hex or decimal format and is the line in which the editing takes
place. The bottom line displays the macro in ASCII format; it is not user configurable.
This line keeps track of which part of the macro you are editing, and is updated by the
utility as editing takes place.
The insert, delete, and cursor control keys are active for editing. When a key is se-
lected from the Edit Macro option, the menu bar displays the following choices: Exit,
Cut, Copy, Paste, Codes, Hex/Decimal, and I/O (Insert/Overtype). The macro for the
chosen key is also displayed.
Cut deletes a sequence of scan codes from the macro. To select a section to cut:
1. Place the cursor on the first character to cut.
2. Press
3. Press
The last character of every macro is the end of the macro (EOM) and cannot be de-
leted.
Copy copies a sequence of scan codes from the macro into memory. To select the
section to copy:
1. Place the cursor on the first character to copy. Press
2. Press
3. Move the cursor on the last character to copy and press
The copied item does not appear on the screen until you select Paste.
Paste inserts a sequence of scan codes (which were saved in memory using Copy)
into the macro. To paste a sequence of scan codes that were previously copied, posi-
tion the cursor where you want the text to appear and then press
then press
Codes section in this chapter for a complete code listing. Hex/Decimal toggles be-
tween displaying the scan codes in Hex and Decimal formats. Insert toggles between
insert and overtype mode.

Upload Menu

Use the Upload Menu to choose which data to load. Choices in this menu are: Combo
Keypad, Keypad Version, and Exit.
Command Description
Combo Keypad Commands the keyboard controller to send its entire macro set for the keypad.
Keypad Version Commands the keyboard controller to send its firmware revision number.
Exit Returns to the Main Menu.
66
.
ENTER
1 and select
F
CUT
. Cut should still be highlighted, but the cursor will appear on the Edit
ENTER
line. Move the cursor on the last character to cut and press
. Copy should still be highlighted, but the cursor will appear on the
ENTER
Edit line.
. Codes displays a table of keys and their scan codes in Hex. See the
ENTER
Only one macro set may reside in memory at one time.
.
Note
.
ENTER
1 and select Copy.
F
.
ENTER
1. Select Paste and
F
