OPERATION
2.5.3

Secondary Parameters Page

Parameter Description
CELL T
PCB TEMP
COMP I/P
EXT I/P
14
CELL T, °C
PCB TEMP, °C
COMP I/P
EXT I/P
Figure 12
Sensor cell temperature display in set unit (°C, °F or Kelvin)
Display Resolution = 0.1
Temperature display of Microcontroller in selected temperature unit
This gives an indication of the internal temperature
Display Resolution = 1 unit
Accuracy = ±2ºC
The value of compensation input (mA i/p channel 1) as a % (4 mA=0%
and 20 mA=100%)
OFF displayed instead of value if external compensation is turned off
Value of the external input in the selected parameter and unit
(DEWP, TEMPR, PRESS or NONE)
OFF displayed instead of value if external compensation parameter is set
to NONE
XTP501 & XTC501 User's Manual
50.0
28
OFF
OFF
Secondary Parameters Page
99976 Issue 1.1, May 2020
