Value
246
247
Only if an "I(N), I(diff), analog expansion module" is used.
*)
See also
Configuration settings with the function codes 0x03, 0x04, and 0x10 (Page 192)
A.2.16

Communication settings with the function codes 0x03, 0x04, and 0x10

Addressing the communication settings
Table A- 21 Communication settings
Offset Number of
registers
62983 2
62985 2
62987 2
62989 2
62991 2
62993 2
63001 2
PAC4200
System Manual, 05/2019, A5E02316180B-05
Assignment
I5 Module Slot 2
*)
I6 Module Slot 2
*)
Name Format
Aggregation file 1 Unsigned long
(period length)
Aggregation file 1 Unsigned long
(method)
Aggregation file 2 Unsigned long
(period length)
Aggregation file 2 Unsigned long
(method)
Aggregation file 3 Unsigned long
(period length)
Aggregation file 3 Unsigned long
(method)
IP Address Unsigned long
Unit Applicable
MODBUS function
codes
s
0x03
•
0x04
•
0x10
•
-
0x03
•
0x04
•
0x10
•
s
0x03
•
0x04
•
0x10
•
-
0x03
•
0x04
•
0x10
•
s
0x03
•
0x04
•
0x10
•
-
0x03
•
0x04
•
0x10
•
-
0x03
•
0x04
•
0x10
•
Appendix
A.2 Modbus
Value range Access
>3 s RW
0: AUTO RW
1: RMS
2: ARITHMETIC
>3 s RW
0: AUTO RW
1: RMS
2: ARITHMETIC
>3 s RW
0: AUTO RW
1: RMS
2: ARITHMETIC
0 ... FFFFFFFFh RW
