Index

A
AC current, 72
Acknowledgable events, 82
Alternating current measurement, 16
Alternating voltage measurement, 16
Applying the measuring current, 72
Applying the measuring voltage, 71
Arc flashover, 57
B
Battery, 47, 130
Battery compartment, 42, 47, 125
Bit mask, 153, 155
C
Circuit breaker, 46
Cleaning, 121
Clearance dimensions, 48, 143
Clearances, 143
Communication, 132
Components of the product, 7
Connection elements, 133
Connection examples, 58
Connection type, 17
Check, 72
Current measurement, 16
Current measuring inputs
Protecting, 57
Current transformers, 72
D
Degree of protection, 136
Deinstallation, 51
Detergents, 121
Device identification parameters, 212
Digital input, 130
Digital output, 131
PAC4200
System Manual, 05/2019, A5E02316180B-05
Dimensions, 141
Clearance dimensions, 143
Clearances, 143
Frame dimensions, 142
Panel cutout, 141
Ring lug, 134
Direction of current flow, 72
Disposal, 126
E
Error code, 146
Ethernet cable, 65
Ethernet ports, 132
Event recording, 82
Events
Acknowledgable, 82
Settings in the SENTRON software, 85
Extra-low voltage power supply, 16, 68, 71
F
Fail-safe power supply, 122
Firmware update, 122
Duration, 122
Fixed block method, 192
Frame dimensions, 142
Function code, 155, 192, 212
G
General safety notes, 9
Grounding, 57, 65
H
Humidity, 121
I
Information, 7
