3.2

Inserting the battery

Hazardous voltage.
Will cause death or serious injury.
Turn off and lock out all power supplying this equipment before working on this device.
For first start-up, use the battery supplied with the device (3 V lithium button cell type:
CR2032). If you use another battery, this must meet the requirements listed in the chapter
"Technical data".
Note
Use only batteries tested in accordance with UL1642.
Take note of the polarity indicated at the insertion opening of the battery compartment. Insert
the battery into the battery compartment.
Note
Polarity of the battery
The opening of the battery compartment has the same shape as the battery. This determines
the alignment of the terminals. It is not possible to insert the battery incorrectly.
Figure 3-2
See also
Technical data (Page 127)
PAC4200
System Manual, 05/2019, A5E02316180B-05
DANGER
Using the battery
