8-8 C 8: A
HAPTER DMINISTERING
Top-Level Menu
system
display
ethernet
station
tvxLowerBound
fddi
path
tmaxLowerBound
bridge
mac
maxTreq
ip
port
snmp
analyzer
script
logout
Setting
tmaxLowerBound
Top-Level Menu
system
display
ethernet
station
tvxLowerBound
fddi
path
tmaxLowerBound
bridge
mac
maxTreq
ip
port
snmp
analyzer
script
logout
FDDI R
ESOURCES
To set tvxLowerBound:
1 From the top level of the Administration Console, enter:

fddi path tvxLowerBound

You are prompted for a station, path, and value. The Switch 2200 has one
station, which appears in brackets.
2 Press [Return].
3 Enter the path (
p
4 Enter the new minimum time value.
The default is 2500 microseconds ( s).
See the following example:
Select station [1]:
Select path(s) (p,s|all) [p]:
Station 1 Primary - Enter new value [2500]:
The tmaxLowerBound attribute specifies the minimum time value of
fddiMAC T-Max that will be used by any MAC that is configured onto this
path. This value specifies the boundary for how high T-Req (the requested
token rotation time) can be set.
To set tmaxLowerBound:
1 From the top level of the Administration Console, enter:

fddi path tmaxLowerBound

You are prompted for a station, path, and value. The Switch 2200 has one
station, which appears in brackets.
2 Press Return.
3 Enter the path (
p
4 Enter the new minimum time value.
The default is 165000 microseconds ( s).
See the example below:
Select station [1]:
Select path(s) (p,s|all) [p]:
Station 1 Primary - Enter new value [165000]:
= primary, = secondary).
s
= primary, = secondary).
s
