FDDI Menu

From the fddi menu, you can view information about and configure the
FDDI station, paths, MAC, and ports. (See Figure 2-3.) For example, to enable
the LLC service of the FDDI MAC, you enter fddi at the top-level menu, mac
at the fddi menu, and then llcService at the mac menu.
Top-Level Menu fddi menu
system
ethernet
fddi
bridge
ip
snmp
analyzer
script
logout
Figure 2-3 FDDI Menu Hierarchy for Administer Access

Bridge Menu

From the bridge menu, you can view information about and configure
bridge-level parameters, including those for the Spanning Tree Protocol
(STP). You can also configure the bridge at the port level and administer
packet filters. (See Figure 2-4.) For example, to set the Spanning Tree state
for a bridge port, you enter bridge at the top-level menu, port at the
bridge menu, and stpState at the port menu.
Using Menus to Perform Tasks
station menu
display
station
connectPolicy
path
tNotify
mac
statusReporting
port
path menu
display
tvxLowerBound
tmaxLowerBound
maxTreq
mac menu
summary
detail
frameErrorThreshold
notCopiedThreshold
llcService
path
port menu
display
lerAlarm
lerCutoff
label
path
2-5
