3Com SUPERSTACK 2200 User Manual page 37

# This script performs some start-up configurations.
#
# Set the Console serial port baud rate.
#
system consoleSpeed
300
#
# Set the system name
#
system name
Engineering Switch2200_4
#
# Assign an IP address to the Switch 2200.
#
ip interface define
158.101.112.99
255.255.0.0
158.101.255.255
1
all
#
ip interface display
#
# Validate access to management workstation
#
ip ping
158.101.112.26
#
# Enable the Spanning Tree Protocol
#
bridge stpState enabled
#
# Configure my node as an SNMP trap destination
#
snmp trap add
158.101.112.26
all
q
#
snmp trap display
#
Running Scripts of Administration Console Tasks
# Console port baud rate
# IP address for the system
# subnet mask
# broadcast address
# cost
# ports
# management workstation address
# management workstation address
# turn on all traps
# no more trap destinations
2-15
