Adding an
Analyzer Port
Top-Level Menu
system
display
ethernet
add
fddi
remove
bridge
start
ip
stop
snmp
analyzer
script
logout
Port selection errors
To display the roving analysis configurations, enter the following from the
top level of the Administration Console:
analyzer display
The configurations are displayed as shown in the following example:
Ethernet ports configured as analyzer ports:
Ethernet Port
Ethernet ports being monitored:
Ethernet Port
You can have as many as 16 network analyzers connected to a system (the
maximum number of Ethernet ports on a system). For a more accurate
analysis, attach the analyzer to a dedicated Ethernet port instead of through
a repeater.
To add analyzer ports:
1 From the top level of the Administration Console, enter:
analyzer add
2 Press Return to select Ethernet as the port type.
3 Enter the number of the Ethernet port to which the network analyzer is
attached.
The MAC address of the analyzer port is displayed. You will need this
information for setting up the port you want to monitor. See the following
example:
Select Ethernet port (1-16):
Analyzer port address is 00-80-3e-0a-3b-02
If your port selection is not valid, you receive one of the following
messages:
Error adding analyzer - monitoring already configured on
this port
Error adding analyzer - analyzer already configured on this
port
9 00-80-3e-0a-3b-02
16 00-80-3e-0a-3b-02
9

Adding an Analyzer Port
