Setting Tvxlowerbound - 3Com SUPERSTACK 2200 User Manual

3 Enter the path (
Setting
tvxLowerBound
= primary,
p
See the following example of path information:
stn path
1 primary
1 secondary
1 local
stn path
1 primary
1 secondary
1 local
Table 8-3 describes these statistics.
Table 8-3 Description of Fields for FDDI Path Attributes
Field Description
maxTReq Maximum time value of fddiMACT-Req that will be used by any
MAC that is configured in this path. This value can be user-defined.
ringLatency Total accumulated latency of the ring associated with this path
tmaxLowBound Minimum time value of fddiMACT-Max that will be used by any
MAC that is configured in this path. This value can be user-defined.
traceStatus Current Trace status of the path
tvxLowBound Minimum time value of fddiMACTvxValue that will be used by any
MAC that is configured in this path. This value can be user-defined.
The tvxLowerBound attribute specifies the minimum time value of fddiMAC
TvxValue that will be used by any MAC that is configured onto this path. A
MAC uses its valid transmission timer (TVX) to detect and recover from
certain ring errors. If a valid frame has not passed through a MAC during the
time indicated by fddiMACTvxValue, the MAC reinitializes the ring.
By adjusting the tvxLowerBound value, you specify how quickly the ring
recovers from an error. The lower you set this value, the faster the network
reacts to problems, but the ring might be reinitialized when there is no
problem. The higher you set this value, the less chance of frequent
reinitializations, but the network will take longer to recover from errors.
= secondary).
s
ringLatency traceStatus
16
16
0
tvxLowBound tMaxLowBound
2500 us 165000 us
2500 us 165000 us
2500 us 165000 us
Administering FDDI Paths
0x0
0x0
0x0
maxTReq
165000 us
165000 us
165000 us
8-7
