7-4 C 7: A
HAPTER DMINISTERING
E P
THERNET ORTS
Table 7-1 Description of Fields for Ethernet Port Attributes (continued)
Field Description
portLabel 32-character string containing a user-defined name. The maximum
length of the string is 32 characters, including the null terminator.
portState Current software operational state of this port. Possible values are
on-line and off-line.
portType Specific description of this port's type.
requestedState Configurable parameter used to enable and disable this port. The
default is enabled.
rxByteRate Average number of bytes received per second by this port during
the most recent sampling period
rxBytes Number of bytes received by this port, including framing characters
rxDiscards Number of received frames discarded because there was no higher
layer to receive them or because the port was disabled
rxErrs Sum of all receive errors associated with this port (summary report
only)
rxFrameRate Average number of frames received per second by this port during
the most recent sampling period. Sampling periods are 1 second
long and are not configurable.
rxFrames The number of frames copied into receive buffers by this port
rxInternalErrs Number of frames discarded because of an internal error during
reception
rxMulticasts Number of multicast frames delivered to a higher-level protocol or
application by this port
rxPeakByteRate Peak value of ethernetPortByteReceiveRate for this port since the
station was last initialized
rxPeakFrameRate Peak value of ethernetPortFrameReceiveRate for this port since the
station was last initialized
rxUnicasts Number of unicast (nonmulticast) frames delivered by this port to a
higher-level protocol or application
txByteRate Average number of bytes transmitted per second by this port
during the most recent sampling period
txBytes Number of bytes transmitted by this port, including framing
characters
txDiscards Number of transmitted frames discarded because the port was
disabled
txErrs Sum of all transmit errors associated with this port (summary report
only)
(continued)
