8-2 C 8: A
HAPTER DMINISTERING
Displaying Station
Information
Top-Level Menu
system
display
ethernet
station
connectPolicy
fddi
path
tNotify
bridge
mac
statusReporting
ip
port
snmp
analyzer
script
logout
FDDI R
ESOURCES
When you display FDDI station information, you receive information about
the station, including its configuration, status reporting, and the most
pertinent statistics about general station activity and errors.
1 Enter the following from the top level of the Administration Console:
fddi station display
You are prompted for a station. The Switch 2200 has only one station, which
appears in brackets.
2 Press [Return].
See the following example of station information:
configuration
isolated
ecmState remoteDisconect
in
00-00-00-80-3e-02-95-00
Table 8-1 describes these statistics.
Table 8-1 Description of Fields for FDDI Station Attributes
Field Description
configuration Attachment configuration for the station or concentrator. Values
can be Thru, Isolated, Wrap_A, and Wrap_B.
connectPolicy Bit string representing the connection policies in effect on a
station. How connection policies translate into bits is described in
Table 8-2. This value can be user-defined.
ecmState Current state of the ECM state machine
remoteDisconnect Flag indicating that the station was remotely disconnected from
the network as a result of receiving an fddiSMTAction with the
value of disconnect in a Parameter Management Frame (PMF). A
station requires a Connect Action to rejoin and clear the flag.
stationID Unique identifier for an FDDI station
statusReporting Value indicating whether statusReporting is enabled or disabled for
the station. This attribute controls whether a station generates
Status Report Frames (SRFs) to report events and conditions to
network management stations. This value can be user-defined.
(continued)
tNotify statusReporting
30 enabled
traceMaxExp
false 87500000
stationId
connectPolicy
0x8000
