Evco C-PRO CLIMA SYSTEMA Installer Manual page 78

9.3.3 Zone humidity work set-point (MCZN module)
The zone humidity work set-point is decided in manual mode via the relative maintenance technical
parameters present in the c-pro micro MCZN zone regulator or automatically, set by the final user
via programmed weekly time bands.
To set the automatic humidity work set-points (Economy and Comfort set-points), consult the c-pro
CLIMA system user manual.
Important parameters:
MCZN: Maintenance Menu
MCZN: Maintenance Menu
9.3.4 Management and configuration of the c-pro micro MCDE module for
As well as direct control of the manifold/zone dehumidification valve, the c-pro CLIMA system has
the possibility of managing various types of additional dehumidifiers via CANbus, equipped with
utilities (fans/batteries) dedicated to increasing heating/cooling capacities of the controlled system.
To use these types of additional dehumidifiers, the c-pro micro MCDE module must be used.
As previously described, the additional dehumidifiers can be associated to a zone regulator and can
serve just one of the controlled areas (Zone A or Zone B) or both, depending on the type and size of
the controlled rooms.
Depending on the type of dehumidifier used in the system, via the relevant parameter, the c-pro
micro MCDE module assumes a different functioning type, varying the type of utility managed by
the digital outputs, as follows:
Digital outputs configuration
Dehumidif. type 0:
Dehumidif. type 1:
Dehumidif. type 2:
Important parameters:
MCZN: Installer Menu
MCZN: Installer Menu
MCDE: Installer menu
MCDE: Installer menu
MCDE: Installer Menu
MCDE: Maintenance Menu
MCDE: Maintenance Menu
C-PRO CLIMA SISTEMA INSTALLER MANUAL
Zone A(B) Maintenance
Zone A(B) Maintenance
additional dehumidifiers (MCZN, MCDE modules)
DO1 = zone A dehumidifier
DO2 = not used
DO3 = zone B dehumidifier
DO1 = dehumidifier
DO2 = heating booster
DO3 = cooling booster
DO1 = zone A dehumidifier
DO2 = heat./cool. booster zone A
DO3 = zone B dehumidifier
Dehumidifier
Dehumidifier
General parameters
General parameters
Dehumidifyer
General parameters
General parameters
Humid. regulation
H. Regulation
DO4 = not used
DO5 = zone A dehumidif. alarm
DO6 = zone B dehumidif. alarm
DO4 = fresh air damper
DO5 = dehumidifier alarm
DO6 = not used
DO4 = heat./cool. booster zone B
DO5 = zone A dehumidif. alarm
DO6 = zone B dehumidif. alarm
Rem. dehumidifier
Rem. dehumidifier
MCZN assigned
CANBUS address
Dehum. type
Regulations
Regulations
Page 78
COMFORT
ECONOMY
Enab. control
CANBUS address
Dehumidifyer
Dehum. delay
