Evco C-PRO CLIMA SYSTEMA Installer Manual page 35

Maintenance L1 Value of the floating delivery 1 set-point relative to the
Mixing valve S maximum external temperature in Summer mode
Setpoint 2 (expressed in °C)
Maintenance L1 Fixed value of the delivery 1 floating set-point in
Mixing valve S summer mode if the function is disabled due to alarm
Fix setpoint (expressed in °C)
Winter mixing valve 1 functioning mode
Maintenance L1
- Closed
Mixing valve W
- Modulating
Mode
- Openend
Maintenance L1 Minimum external temperature in winter for the
Mixing valve W calculation of the delivery 1 floating set-point (expressed
Min.Ext.T. in °C)
Maintenance L1 Maximum external temperature in winter for the
Mixing valve W calculation of the delivery 1 floating set-point (expressed
Max.Ext.T. in °C)
Maintenance L1 Value of the floating delivery 1 set-point relative to the
Mixing valve W minimum external temperature in Winter mode
Setpoint 1 (expressed in °C)
Maintenance L1 Value of the floating delivery 1 set-point relative to the
Mixing valve W maximum external temperature in Winter mode
Setpoint 2 (expressed in °C)
Maintenance L1 Fixed value of the delivery 1 floating set-point in winter
Mixing valve W mode if the function is disabled due to alarm (expressed
Fix setpoint in °C)
Maintenance L1
Mixing valve 1 regulation proportional band (expressed
M.Valve regulation
in °C)
Prop. Band
Maintenance L1
Integral time for regulation of mixing valve 1 (expressed
M.Valve regulation
in seconds)
Integr. time
Maintenance L1
Valve 1 opening percentage with fixed opening
M.Valve regulation
regulation (expressed as % opening)
Fix opening
Maintenance L1
M.Valve regulation Opening time valve 1 (sec)
Opening time
Maintenance L1
M.Valve regulation Extra time of limit switch open / close valve 1 (sec)
Extra time
Maintenance L1
Percentage of minimum variation of valve 1 to enable
M.Valve regulation
the movement (expressed in % of opening)
Min variation
Maintenance L1
Enabling of activation of mixing valve 1 for anti-grip
M.Valve regulation
cycle
Antigrip enab.
Maintenance L1
Opening percentage of mixing valve 1 during antigrip
Mix V regulation
cycle (expressed in % of opening)
Antigrip open
Maintenance L1
Delivery 1 high temperature limit for delivery high
Temperature limits
temperature alarm activation (expressed in °C)
HT setpoint
Maintenance L1
Hysteresis (differential) relative to delivery 1 high
Temperature limits
temperature limit (expressed in °C)
HT hyst.
Maintenance L1
Delivery 1 low temperature limit for delivery 1 low
Temperature limits
temperature alarm activation (expressed in °C)
LT setpoint
Maintenance L1
Hysteresis (differential) relative to delivery 1 low
Temperature limits
temperature limit (expressed in °C)
LT hyst.
C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 35
7.0 0.0
7.0 0.0
MODUL. CLOSED
5.0 -30.0
10.0 0.0
35.0 0.0
25.0 0.0
35.0 0.0
5.0 0.0
0 0
20.0 0.0
150 0
5 0
2.0 0.0
Yes No
100.0 0.0
45.0 0.0
5.0 0.0
10.0 -10.0
5.0 0.0
40.0
40.0
OPENED
30.0
30.0
90.0
90.0
90.0
10.0
65535
100.0
3600
600
20.0
Yes
100.0
90.0
10.0
40.0
10.0
