- Page 1 EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 c-pro 3 nano CHILL Programmable controllers for chillers/heat pumps with single or dual circuit Application manual ver. 3.0 November 2019 | ENGLISH Codice 144CP3NCE304...
- Page 2 EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 IMPORTANT WARNING Read the User Manual carefully before installation and before use and follow all the instructions concerning installation and electrical connections. This manual must be kept for future consultation.
-
Page 3: Table Of Contents
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 INTRODUCTION ............................6 Introduction ............................6 APPLICATIONS ............................7 Basic scheme of application of an air/water dual-circuit chiller ..............8 HARDWARE SOLUTIONS .......................... 9 MEASUREMENTS ........................... 10 Controller and user interface measurements .................. - Page 4 EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 Compressor Management ........................55 8.7.1 Compressor State ......................... 55 8.7.2 Compressor Rotation......................56 8.7.3 Pump-down Switch-off Procedure ................... 56 8.7.4 Relative Pump-down Threshold ....................57 8.7.5 Protection Periods .........................
- Page 5 EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 8.22.8 Setpoint variation from digital input ..................76 8.23 Management of the EVDRIVE03 built into the system ................77 8.23.1 Enablement of EEV Operation ....................77 8.23.2...
-
Page 6: Introduction
INTRODUCTION Introduction The programmable controllers in the c-pro 3 nano CHILL line are devices designed to manage chillers/heat pumps with single and dual circuit with a maximum of three scroll compressors per circuit. They use programmable controllers, the expansions of I/O, and the remote user interfaces of the c-pro 3 line and are programmed with a software application implemented with the UNI-PRO 3 development environment. -
Page 7: Applications
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 APPLICATIONS The controllers can manage the following types of unit: Air/water single-circuit Air/water single-circuit chiller Air/water single-circuit chiller with EEV driver Air/water single-circuit chiller + Heat pump... -
Page 8: Basic Scheme Of Application Of An Air/Water Dual-Circuit Chiller
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 Basic scheme of application of an air/water dual-circuit chiller page 8 of 96... -
Page 9: Hardware Solutions
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 HARDWARE SOLUTIONS Hardware Item Code Controller c-pro 3 nano CHILL EPN2LXP I/O expansion c-pro 3 EXP micro+ EPU2EXP EEV driver (built-in version) EVDRIVE03 EPD4DF3 EEV driver (blind version) -
Page 10: Measurements
3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 MEASUREMENTS Controller and user interface measurements Below we show the measurements, assembly, and electrical connections of the c-pro 3 nano CHILL device. 4.1.1 c-pro 3 nano CHILL control module measurements To be fitted to a panel;... -
Page 11: Epjgraph Remote User Interface Measurements
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 4.1.1 EPJgraph remote user interface measurements Models for panel mounting; measurements are in mm (in). N.B. - the thickness of a metal panel must be between 0.8 and 1.5 mm (1/32 and 1/16 in), while that for a plastic panel must be between 0.8 and 3.4 mm (1/32 and 1/8 in) - Page 12 EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 Models for wall mounting; measurements are in mm (in). Wall mounting (with bolts and fastening screws) or in the most common flush mounting boxes (with fastening screws).
-
Page 13: Vgraph Remote User Interface Measurements
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 4.1.2 Vgraph remote user interface measurements To be fitted to a panel; measurements are in mm (in). 4.1.3 EVDRIVE03 module measurements 4 DIN modules, installation with assembly on DIN rail; measurements are in mm(in). -
Page 14: User Interface
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 USER INTERFACE Two types of interface are provided for the application: • interface with built-in LED display (4 keys) • remote interface with EPJgraph LCD display (6 keys) •... -
Page 15: Vgraph User Interface
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 5.1.2 Vgraph user interface: The terminal’s main characteristics are the chance to communicate a remarkable amount of information to the user and how extremely easy it is to use; these characteristics derive from a graph viewer and a six-key membrane keyboard (with preset functions) and the CAN bus (to connect to the controllers). -
Page 16: List Of The Pages
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 LIST OF THE PAGES This chapter describes the main pages and the menus in the application. As described above, the general menu is divided up into four levels of submenu: user, maintenance operator, installation operator, and configuration. -
Page 17: Unit Off Main Screen
T External Display c-pro 3 nano CHILL The display of c-pro 3 nano CHILL will show: in the upper row the inlet temperature of the utility exchanger and in the lower row the outlet temperature of the utility exchanger. At the bottom of the page some icons are shown to indicate some operating modes of the circuit. -
Page 18: Stat Menu
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 The table below shows the individual icons, their operating state, and what is verified. From left to right: Icon Operating mode Event shown If there is an active alarm, the alarm icon will be shown in place of the operating... -
Page 19: Led Meaning
EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 Page 1 rEGP Main regulation probe Page 1 PREq Power requested [%] Page 1 PSup Power supplied [%] Table with examples system modes viewable from Page 2... - Page 20 EVCO S.p.A. c-pro 3 nano CHILL | Application manual ver. 3.0 | Code 144CP3NCE304 if on and blinking back, it means that a compressor in the circuit is on in manual LED compressor2 /step 2 If on, it means that at least one compressor in the circuit 2 is active;...
