Evco C-PRO CLIMA SYSTEMA Installer Manual page 48

Type of terminal units present in zone A
Zone A setup
- H.T. = High temperature (radiators)
Terminal units
- L.T. = Low temperature (floor heating/cooling)
Type of probe installed in Zone A
- --- = Not present
- T = Temperature
Zone A setup
- T+Set = Temperature + remote set-point variator
Sensor type
- TH = Temperature + humidity
- TH+Set = Temperature + humidity + remote
Analogue input to which the Zone A temperature probe
is to be associated
- --- = no measurement input (probe not present)
Zone A setup
- AIn1 = analogue input 1
T. probe pos.
- AIn2 = analogue input 2
- AIn3 = analogue input 3
- AIn4 = analogue input 4
Analogue input to which the Zone A humidity transducer
is to be associated
Zone A setup
- --- = no measurement input (transd. not present)
H. probe pos.
- AIn3 = analogue input 3
- AIn4 = analogue input 4
Analogue input to which the Zone A remote set-point
variator is to be associated
- --- = no measurement input (variator not present)
Zone A setup
- AIn1 = analogue input 1
Rem. set pos.
- AIn2 = analogue input 2
- AIn3 = analogue input 3
- AIn4 = analogue input 4
Enables the regulation mode for Zone A
- OFF = Regulation not active
Zone A setup
- E = Regulation only in summer mode (cooling)
Reg. type
- I = Regulation only in winter mode (heating)
- E/I = Regulation in summer and winter mode
Digital output configuration DO3 associated to Zone A
Zone A setup
- ALR = Zona A generic alarm
D output cfg
- BOOST = integration at heating/cooling Zone A
Zone A setup Enable use of delivery line water (circulation pump) for
Dehum. with H2O dehumidification
Zone A setup
Zone probe signal Type of transducer used to detect humidity
Probe type
Zone A setup Minimum calibration value of the humidity transducer,
Zone probe signal corresponding to the 4mA or 0V of the transducer
Min H. value (expressed in %r.H.)
Zone A setup Maximum calibration value of the humidity transducer,
Zone probe signal corresponding to the 20mA or 5V of the transducer
Max H. value (expressed in %r.H.)
Calibration points for remote setpoint variator calibration
(expressed in points)
Zone A setup
- P1 = maximum negative variation
R.Set calibr.
- P2 =neutral position
- P3 = maximum positive variation
Rem. dehumidifyer Enabling of presence of a MCDE module for additional
Enable control dehumidifiers associated to the MCZN regulator
Rem. dehumidfiyer MCDE module CAN address
CANBUS address (assigned automatically by the system)
C-PRO CLIMA SISTEMA INSTALLER MANUAL
set-point variator
* The same menu is also available for Zone B
REM. DEHUMIDIFIER
Page 48
L.T. H.T.
T ---
AIn1 ---
AIn3 ---
--- ---
E/I OFF
ALR ALR
Yes No
4-20mA 4-20mA
0.0 0.0
100.0 0.0
0 999
No No
0 0
L.T.
TH+Set
AIn4
AIn4
AIn4
E/I
BOOST
Yes
0-5V
100.0
100.0
999
Yes
55
