Evco C-PRO CLIMA SYSTEMA Installer Manual page 65

Panels maintenance
Stag.emergency
Panels maintenance
ON hyst.
Panels maintenance
OFF hyst.
Panels maintenance
Temperature limits
HT setpoint
Panels maintenance
Temperature limits
HT hyst.
Panels maintenance
Temperature limits
LT setpoint
Panels maintenance
Temperature limits
LT hyst.
Aux 1 Maintenance
Mode
Aux 1 Maintenance
Contr. probe
Aux1 Maintenance
Setpoint
Aux1 Maintenance
Hysteresis
Aux1 Maintenance
Offset ON
Aux1 Maintenance
Offset OFF
Aux1 Maintenance
Probe offset
Aux1 Maintenance
HT setpoint
Aux1 Maintenance
HT hyst.
Aux1 Maintenance
LT setpoint
Aux1 Maintenance
LT hyst.
C-PRO CLIMA SISTEMA INSTALLER MANUAL
Anti-stagnation emergency management mode
- ON/OFF = via a heat disposal ON-OFF valve
- Cover1 = via cover opening closing management (on
same relay contact)
- Cover2 = via cover opening closing management (on
two relay contacts)
Offset (differential) solar panels pump connection,
relative to work set-point.
(expressed in °C)
Offset (differential) solar panels pump disconnection,
relative to work set-point.
(expressed in °C)
Solar panels circuit water high temperature alarm set-
point
(expressed in °C)
Solar panels circuit water high temperature alarm set-
point differential, relative to the high temperature
alarm set-point
(expressed in °C)
Solar panels circuit water low temperature alarm set-
point
(expressed in °C)
Solar panels circuit water low temperature alarm set-
point differential, relative to the low temperature alarm
set-point
(expressed in °C)
AUX 1 MANAGEMENT
Auxiliary circuit 1 circulation pump regulation mode:
- CONT. = Continuous
- T.RICH. = On temperature request
Circuit connected with AUX1 for differential
temperature control for AUX1circulation pump
activation:
- DHW = heat exchange with DHW tank
- SOL = heat exchange with solar panel
Auxiliary 1 circuit water temperature set-point
(expressed in °C)
Hysteresis (differential) for auxiliary circuit circulation
pump start
(expressed in °C)
Temperature differential between control probe and
AUX1 probe for auxiliary circuit circulation pump
activation
(expressed in °C)
Temperature differential between control probe and
AUX1 probe for auxiliary circuit circulation pump
deactivation
(expressed in °C)
Auxiliary circuit 1 probe calibration (offset)
(expressed in °C)
Auxiliary circuit 1 high temperature alarm set-point
(expressed in °C)
High temperature alarm differential (Hysteresis)
relative to the high temperature alarm set-point
(expressed in °C)
Auxiliary circuit 1 low temperature alarm set-point
(expressed in °C)
Low temperature alarm differential (Hysteresis)
relative to the low temperature alarm set-point
(expressed in °C)
Page 65
ON/OFF ON/OFF
10.0 0.0
5.0 -50.0
130.0 0.0
20.0 0.0
5.0 -10.0
5.0 0.0
T.RICH. CONT.
SOL DHW
60.0 35.0
5.0 0.0
10.0 -50.0
5.0 -50.0
0.0 -10.0
70.0 0.0
5.0 0.0
10.0 -10.0
5.0 0.0
Cover2
50.0
50.0
200.0
50.0
40.0
10.0
T.RICH.
SOL
80.0
20.0
50.0
50.0
10.0
90.0
10.0
40.0
10.0
