Evco C-PRO CLIMA SYSTEMA Installer Manual page 56

Booster Parameters
Booster H
Booster Parameters
Booster C
Booster Parameters
Set deh1 in
Booster Parameters
Set deh2 in
Booster Parameters
Dehum. activ.
CO2 parameters
Enable reg.
CO2 parameters
Dumper mode
CO2 parameters
Setpoint
CO2 regulation
Hysteresis
7.7.2 List of INSTALLER menu configuration parameters
Label Parameter description
AIn3 analogue input configuration type:
I/O configuration
- 4-20mA
AIn3
- 0-5V
Type of contact for digital inputs
I/O configuration NA = normally open
DIn NC = normally closed
General parameters MCZN zone regulator to which the MCDE module is
MCZN assigned associated
General parameters
CANbus serial address
CANBUS address
CANbus communication speed (baud rate)
-20Kbit
General parameters -50Kbit
Baud Rate -125Kbit
-500Kbit
C-PRO CLIMA SISTEMA INSTALLER MANUAL
Zone assignment (of the associated MCZN regulator)
to which the heating integration Hot Booster function
is associated:
- --- = no Zone associated
- ZA = associated to Zone A
- ZB = associated to Zone B
- ZA+ZB associated to Zone A and Zone B
Zone assignment (of the associated MCZN regulator)
to which the cooling integration Cold Booster function
is associated:
- --- = no Zone associated
- ZA = associated to Zone A
- ZB = associated to Zone B
- ZA+ZB associated to Zone A and Zone B
Minimum input temperature dehumidifier 1 setpoint
for enabling of Heating Booster
(expressed in °C)
Minimum input temperature dehumidifier 2 setpoint
for enabling of Heating Booster
(expressed in °C)
Link between the activation of the booster output and
the activation of the dehumidifier output
Enabling regulation of the CO2 level
Fresh air dumper functioning mode:
- --- = not enabled
- CLOSED = fixed
- MODUL. = modulating
- OPEN = fixed
Room maximum CO2 level setpoint due to dumper
opening
(expressed in parts per million)
Hysteresis (differential) relative to the CO2 setpoint
(expressed in parts per million)
I/O CONFIGURATION
GENERAL PARAMETERS
CO2
Page 56
ZA+ZB ---
ZA+ZB ---
35.0 0.0
35.0 0.0
Yes No
Yes No
MODUL. ---
0 0
10 0
Default Min
4-20mA 4-20mA
N.O. N.C.
1 1
0 0
125Kbit 20Kbit
ZA+ZB
ZA+ZB
100.0
100.0
Yes
Yes
OPEN
2000
100
Max
0-5V
N.O.
8
255
500Kbit
