Evco C-PRO CLIMA SYSTEMA Installer Manual page 37

4800 baud
9600 baud
19200 baud
General parameters
MODBUS network
Type of MODBUS communication parity
Parity
General parameters
MODBUS network MODBUS communication Bit Stop position
Stop bit
Type of delivery line 1
Line 1 configuration
H.T. = High temperature (radiators)
Line type
L.T. = Low temperature (floor)
Line 1 configuration
Enabling of mixing valve 1
M.Valve enable
Type of digital input for protection of circulation pump 1
Configure line 1
LOCK = protection input
Pump DIn alr
FLOW = Flow switch
C-PRO CLIMA SISTEMA INSTALLER MANUAL
DELIVERY LINES
* The same menu is also available for the delivery 2 line
Page 37
EVEN NO
1b 1b
L.T. H.T.
Yes No
FLOW LOCK
EVEN
2b
L.T.
Yes
FLOW
