3.4 Regulators network configuration

The c-pro CLIMA system is based on the CANbus communication between the various control
modules present in the network, with the following maximum configuration:
• N° 1 c-pro Mega MCCT thermal power plant regulator
• N° 8 c-pro micro MCZN zone regulators
• N° 8 regulators for additional c-pro micro MCDE dehumidifiers
• N° 1 regulator for c-pro micro MCPS solar panels
Every controller present in the network must be assigned with a different and specific CANbus
address, according to the logic position of the controller inside the c-pro CLIMA network,
following the layout given below:
Type of controller
Thermal power plant regulator
Zone 1 regulator (zones 1-2)
Zone 2 regulator (zones 3-4)
Zone 3 regulator (zones 5-6)
Zone 4 regulator (zones 7-8)
Zone 5 regulator (zones 9-10)
Zone 6 regulator (zones 11-12)
Zone 7 regulator (zones 13-14)
Zone 8 regulator (zones 15-16)
Regulator for dehumidif. associated to zone 1 regulator
Regulator for dehumidif. associated to zone 2 regulator
Regulator for dehumidif. associated to zone 3 regulator
Regulator for dehumidif. associated to zone 4 regulator
Regulator for dehumidif. associated to zone 5 regulator
Regulator for dehumidif. associated to zone 6 regulator
Regulator for dehumidif. associated to zone 7 regulator
Regulator for dehumidif. associated to zone 8 regulator
Regulator for solar panels
As highlighted in the previous table, the controllers are set by default to be automatically recognised
in network as:
• thermal power plant regulator
• zone 1 regulator
• regulator for dehumidifiers
added, associated to zone 1 regulator
• regulator for solar panels
C-PRO CLIMA SISTEMA INSTALLER MANUAL
Page 17
Controller code
c-pro mega MCCT
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCZN
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCDE
c-pro micro MCPS
CANbus 1 address
CANbus 2 address
CANbus 22 address
CANbus 17 address
CANbus
address
1 (default)
2 (default)
3
4
5
6
7
8
9
22 (default)
23
24
25
26
27
28
29
17 (default)
