Evco C-PRO CLIMA SYSTEMA Installer Manual page 47

Zone A Maintenance
Dehumidifier Alarm
Reset type
Zone A Maintenance
Dehumidifier Alarm
Delay
6.7.2 List of INSTALLER menu configuration parameters
Label Parameter description
I/O configuration
Type of measure input for analogue inputs 1 and 2
AIn1 and AIn2
I/O configuration
Type of measure input for analogue inputs 3 and 4
AIn3 and AIn4
Type of contact for digital inputs
I/O configuration
NA = normally open
DIn 1...4
NC = normally closed
General parameters Number of zone controlled by MCZN module
Local zones nr.
Method of using V-Graph display
General parameters - UNIV.= Public terminal
V-GRAPH mode - AB= Module private terminal
- A+B= Terminal with no zones
General parameters MCZN regulator "logic" position setting in the regulators
MCZN module nr. network
General parameters
CANbus serial address
CANbus Address
CANbus communication speed (baud rate)
-20Kbit
General parameters
-50Kbit
Baud rate
-125Kbit
-500Kbit
General parameters
MODBUS serial port Modbus serial address
Idx
Modbus communication speed (baud rate)
- 1200Kb
General parameters
- 2400Kb
MODBUS serial port
- 4800Kb
Baud
- 9600Kb
- 19200Kb
Type of Modbus communication parity
General parameters
- NO
MODBUS serial port
- ODD
Parity
- EVEN
General parameters
MODBUS serial port Modbus communication Bit Stop position
Stop
Zone A setup Zone A "logic" number with respect to total number of
Plant Zone zones present in the system
Zone A setup
Delivery line (from MCCT) associated to Zone A
Delivery line
C-PRO CLIMA SISTEMA INSTALLER MANUAL
Zone A dehumidifier alarm reset type
-AUTOMATIC
-MANUAL
Zone A dehumidifier alarm delay
(expressed in seconds)
* The same menu is also available for Zone B
I/O CONFIGURATION
GENERAL PARAMETERS
ZONES SETUP
Page 47
AUTOMA AUTOMA
TIC TIC
0 0
Default Min
NTC NTC
4-20mA NTC
N.C. N.C.
2 0
UNIV. UNIV.
1 0
2 0
125Kbit 20Kbit
1 1
9600Kb 1200Kb
EVEN NO
1b 1b
1 1
1 0
MANUA
L
1
Max
NTC
4-20mA
N.O.
2
A+B
8
255
500Kbit
247
19200Kb
EVEN
2b
16
2
