Evco C-PRO CLIMA SYSTEMA Installer Manual page 36

Maintenance L1
Delivery 1 temperature probe calibration
Probes calibration
(expressed in °C)
Temperature
5.9.2 List of INSTALLER menu configuration parameters
Label Parameter description
I/O configuration
Configuration of type of analogue inputs
Analog In.
Digital inputs polarity configuration
I/O configuration
NC = normally closed
Digital In.
NA = normally open
Configuration of minimum and maximum calibration
I/O configuration
values of the analogue outputs (expressed as % of the
Analog out.
analogue value in output)
General parameters Setting the number of zones present in the system
Number of zones
General parameters Setting the number of zone MCZN modules present in
Number of MCZN the system
modules
Setting the number of delivery lines present in the
General parameters
system
Delivery lines
General parameters
Enabling of boiler presence
Enable boiler
Setting the type of cooling unit present
General parameters --- = not present
CH-HP type CH = chiller
CHHP = chiller/heat pump
General parameters
Enabling of MCPS solar panels module presence
Enable MCPS
Minimum temperature threshold relative to the external
General parameters
temperature for switch functioning from heat pump
HP-Boiler switch
functioning at boiler (expressed in °C)
Switch temp.
General parameters Hysteresis (differential) relative to the external
HP-Boiler switch temperature for return to functioning with heat pump
Hysteresis (expressed in °C)
General parameters
Heat pump activation continuous maximum time for
HP-Boiler switch
automatic switch to boiler (expressed in hours)
HP max. time
General parameters
CANBUS network MCCT regulator CANBUS address
Node address
General parameters
CANBUS network Enabling of public V-Graph presence
Vgraph enab.
General parameters
MODBUS network MCCT regulator MODBUS address
Idx
General parameters MCCT regulator MODBUS communication speed
MODBUS network 1200 baud
Baud 2400 baud
C-PRO CLIMA SISTEMA INSTALLER MANUAL
* The same menu is also available for the delivery 2 line
I/O CONFIGURATION
GENERAL PARAMETERS
Page 36
0.0 -10.0
Default Min
NTC NTC
N.O. N.C.
0.0 0.0
1 0
1 0
1 0
Yes No
CH ---
No No
7.0 -20.0
5.0 0.0
3 0
1 1
Yes No
1 1
9600 1200
10.0
Max
NTC
N.O.
100.0
16
8
2
Yes
CHHP
Yes
30.0
10.0
65535
127
Yes
247
19200
