3.1.1 Own-Node Status information

The Own Node Status register (displayed on the Own Node Status menu)
contains the following information:
Own Status Byte
Bit Message
0 Node address duplicate
(1=Error)
1 TW Error (1=Error)
2 Rx Wait Error (1=Error)
3 Initialization Error
(1=Error)
4 Reserved
5 Reserved
6 Reserved
7
Page 76 of 155
FA Control Network Ethernet Communication Module
Description
Indicates the management information on
node number conflicted to see whether any
node having the same node number as the
self node setting exists on the network or not.
Token watchdog time error flag indicates that
transmission processing fails to complete
within the token watchdog time set in the own
node
Indicates that no frame has been received at
network initialization, being a frame receive
waiting status.
Indicates an error is found in an initial setting
or resetting parameter
MVI56E-FLN ♦ ControlLogix Platform
Value
0x0001
0x0002
0x0004
0x0008
0x0010
0x0020
0x0040
0x0080
