4.2.3 Backplane Data Transfer

Block Assignments
In order to exchange data with the processor, the MVI56E-FLN module supports
the following block. The block range refers to the Block ID used to identify each
block.
Input Data
Block Range
0 & -1
1 to 3
4 to 35
1000 to 1004
1100 to 1104
2000
9250
Output Data
Block Range
0 & -1
1 to 3
4 to 35
1000 to 1004
2000
9250
9998
9999
Page 100 of 155
Descriptions
Status Data
Area 1 Data From Common Memory
Area 2 Data From Common Memory
Message Request ACK Blocks (future)
Message Response Blocks (future)
Participation Table Response
Log Data Block
Descriptions
Empty Data Blocks
Area 1 Data To Common Memory
Area 2 Data To Common Memory
Message Request Blocks (future)
Participation Table Request
Log Data Block Request
Warm-boot control block
Cold-boot control block
