Timer Types
Message
Token monitoring time
Allowable refresh cycle time
Refresh cycle measurement time Measurement value in a circulation of a token: Present value.
Allowable minimum frame
interval time
Joining token detection time
Participation request frame
transmission waiting time
Three-circulation waiting time
Token holding timeout time
Trigger frame transmission
waiting time
Page 114 of 155
FA Control Network Ethernet Communication Module
Description
Set from the upper layer (in units of 1 ms).
Calculated from the refresh time only for cyclic transmission.
The maximum value and the minimum value from the start time
are held (in units of 1 ms).
Set from the upper layer. The maximum value on the network is
effective (in units of 100 microseconds).
Fixed value (3 seconds)
Fixed value (self-node number
Fixed value (3 seconds)
Within this time after receipt of a token directed to the self-node,
a token must be transmitted to the next node.
Fixed value ((self-node number mod 8)
MVI56E-FLN ♦ ControlLogix Platform
4 ms
4 ms)
