MVI56E-FLN ♦ ControlLogix Platform
FA Control Network Ethernet Communication Module
Special Blocks
Participation Table Request (Write Block) Output Data
Offset Description
0 2000
1 Number of nodes to report (1 to 10)
2 Index of first node (0 to 255)
3 to 247 Spare
Participation Table Response (Read Block) Input Data
Offset Description
0 Write Block ID Requested
1 Number of nodes to reported (0 to 10)
2 to 21 Participation Data first node
22 to 41 Participation Data second node
42 to 61 Participation Data third node
62 to 81 Participation Data fourth node
82 to 101 Participation Data fifth node
102 to 121 Participation Data sixth node
122 to 141 Participation Data seventh node
142 to 161 Participation Data eighth node
162 to 181 Participation Data ninth node
182 to 201 Participation Data tenth node
202 to 248 Spare
249 2000
Participation Data Structure (20 words)
Offset Description
0 Node Number
1 Node Number (0 if not participating)
2 Token watchdog time
3 Allowable minimum frame interval
4 FL Link status
5 Upper layer status
6 Top Area 1
7 Size Area 1
8 Top Area 2
9 Size Area 2
10 Allowable refresh cycle time
11 Missed count
12 to 13 Rx Version sequence number
14 to 15 Rx Broadcast sequence number
16 to 17 Rx Peer-to-peer sequence number
18 to 19 Tx Peer-to-peer sequence number
