3 Click to select the driver, and then click C
Configure RS-232 DF1 Devices dialog box.
4 Click the A
serial port to work with the selected driver.
5 When you see the message Auto Configuration Successful, click the OK
button to dismiss the dialog box.
Note: If the auto-configuration procedure fails, verify that the cables are
connected correctly between the processor and the serial port on your computer,
and then try again. If you are still unable to auto-configure the port, refer to your
RSLinx documentation for further troubleshooting steps.
ProSoft Technology, Inc.
-C button. RSLinx will attempt to configure your
UTO ONFIGURE
. This action opens the
ONFIGURE
Start Here
