MVI56E-FLN ♦ ControlLogix Platform
FA Control Network Ethernet Communication Module
4.2.2 Data Flow between Module and Processor
The following discussion outlines the flow of data between the two pieces of
hardware (ControlLogix processor and MVI56E-FLN module) and other nodes on
the TCP/IP network.
Module's Cyclic Input Data
Module's Cyclic Output Data
ProSoft Technology, Inc.
Reference
User Manual
Page 99 of 155
