Chapter 6 The Graphical User Interface

6.3 The Home Screen

When an Operator login is employed or the Agility field on the Options screen is selected, the
Home screen (Figure 6-2) will be presented.
Figure 6-2: The Home Screen
When the Initialize All Modules button is selected, the self-test, the homing procedure and the
recognition of the status of all modules and consumables will be performed. The results are
shown at completion of the process (Figure 6-3) and the instrument is then ready for
operation.
