Chapter 6 The Graphical User Interface
6.6.2.4
Consumables Status Screen
The Consumables Status screen (Figure 6-13) provides information about the contents of the
five drawers on the right side of the system. The lock sign indicates that the drawer is locked
and in use for current assays, while the unlocked icon indicates that the drawer is not locked
and could be restocked by the user.
Figure 6-13: Consumables Screen
Agility System Operator's Manual
114
