Chapter 4 Operating the Agility System
As an example, if the microplates that are to be used with the SmartKits that have been loaded
are not present, when the scheduling has been accomplished, the system will indicate that a
microplate that matches a SmartKit assay is required via a white light indicator surrounding
the microplate loading bay. In addition, the icon will be placed at the top of
the screen.
Selecting this alert icon shows the plate to be loaded according to the worklist.
Figure 4-22: Plate Status
A plate nickname can be entered on this screen to aid the user in identifying which plate to
load.
