Chapter 3 System Design

3.2.2 Upper (Reagent) Workspace

The Upper (reagent) workspace (Figure 3-2) has four locations capable of holding reagent
packs or reagent tips and two locations capable of holding microplate holders, deep well strip
holders or mixing well holders.
Figure 3-2: Upper (Reagent Workspace)
