WHEN CONNECTING TO THE NETWORK THROUGH A PC

■ Radio's presetting

The RS-BA1 remotely controls Icom radios using CI-V (Icom Communication Interface) commands. See the CI-V
command table in the radio's instruction manual for details of the functions that can be controlled.

D The following manual settings are required when operating the RS-BA1

Properly preset the items in below table for functions that cannot be controlled by CI-V commands or the item may
cause unwanted actions. See the radio's instruction manual for details of the settings or operation.
NOTE:
• Remove the transverter from the radio, if it is connected.
• To prevent an accidental transmission, we recommend you remove any keyer, keypad or other external equipment
connected to the radio.
• Set the radio to a normal operating mode. The radio cannot receive CI-V commands while in special modes, such
as the firmware update mode or cloning mode.
• If the radio has a Time-Out Timer function, we recommend you enable it to prevent the radio from continuously
transmitting.
Genre
Function RIT function
TX function
∂
Simple band scope
SWR Measurement func-
tion
Timer/Sleep Timer func-
tion
Weather Alert function
Display
RTTY decode screen
Volume
Volume for the RX audio
CI-V CI-V address
CI-V baud rate
CI-V USB Port
CI-V USB Baud Rate
Set mode USB Serial Function
RS-232C Function
* Operation on models without a USB connection cannot be guaranteed.
If you are using the IC-PW1 with the transceiver, be sure to set the CI-V baud rate to 19200 bps. After changing
the transceiver's CI-V settings, be sure to reset the CPU of the IC-PW1 and set the transceiver's CI-V settings on
the IC-PW1. See the IC-PW1 instruction manual for details.
Item
All
All
IC-746PRO*/IC-7000*/IC-7100/
IC-7400*/IC-9100
IC-746PRO*/IC-7000*/IC-7100/
IC-7400*/IC-9100
Radios with the timer function
IC-7100
IC-746PRO*/IC-756PROIII*/IC-7400*
All
All
All
IC-7300/
IC-7850 (Firmware version 1.10 or later)/
IC-7851 (Firmware version 1.10 or later)
IC-7300/
IC-7850 (Firmware version 1.10 or later)/
IC-7851 (Firmware version 1.10 or later)
Radios with a USB (B type) port
Radios with an RS-232C port
Model
21
Setting
Set to OFF.
Set to OFF.
Set to OFF.
Set to OFF.
Set the timer to OFF or to your
schedule.
Set to OFF.
Exit the screen.
Set the volume to a suitable level.
Set an appropriate CI-V address.
Set to 19200 bps (or Auto).
To use the Scope function when
connecting to the USB port, set
to Unlink from [REMOTE].
To use the Scope function when
connecting to the USB port, set
to 115200 (or Auto).
Set to "CI-V" for the selected
connection type.
Set to "CI-V" for the selected
connection type.
