1
BEFORE USING REMOTE CONTROL SYSTEM

■ To allow access from the Internet

Only when you configure the remote control system through the Internet, you need the following settings on your
router.
If you configure the remote control system through the Internet, whether you are operating as a Base station or a
Remote station, you need to configure your router to allow access from the Internet.
To allow the access, configure the 3 port numbers used with the Remote Utility (Example: 50001 to 50003).
Ask the router's manufacturer about how to forward the port.
When connecting to the network through a PC
Port numbers
50001 to 50003
Icom radio
When connecting to the network directly
Default Gateway:
192.168.0.1
Port numbers
50001 to 50003
IP Adress:
192.168.0.10
IC-7851
IC-7850
IC-7800 (firmware version 3.00 or later)
IC-7700 (firmware version 2.00 or later)
(Radio/Server)
Default Gateway:
192.168.0.1
DNS Server Address:
192.168.0.1
Router
Base station
IP Adress:
192.168.0.100
Router
INTERNET INTERNET
Remote station
IP Adress:
192.168.0.100
INTERNET INTERNET
Router
Remote station
13
Default Gateway:
192.168.0.1
DNS Server Address:
192.168.0.1
Port numbers
50001 to 50003
Router
Default Gateway:
192.168.0.1
DNS Server Address:
192.168.0.1
Port numbers
50001 to 50003
IP Adress:
192.168.0.100
