Subnet
IKE Authentication
Method
374
VPN connection through XAuth server in Internet.
L2TP with IPsec Policy - Allow the remote dial-in user to
make a L2TP VPN connection through the Internet. You can
select to use L2TP alone or with IPsec. Select from below:
None - Do not apply the IPsec policy. Accordingly, the

VPN connection employed the L2TP without IPsec
policy can be viewed as one pure L2TP connection.
 Nice to Have - Apply the IPsec policy first, if it is
applicable during negotiation. Otherwise, the dial-in
VPN connection becomes one pure L2TP connection.
Must -Specify the IPsec policy to be definitely applied

on the L2TP connection.
SSL Tunnel – Allow the remote dial-in user to make an SSL
VPN connection through Internet.
OpenVPN Tunnel – Allow the remote dial-in user to set a VPN
connection through OpenVPN.
Specify Remote Node -You can specify the IP address of the
remote dial-in user, ISDN number or peer ID (used in IKE
aggressive mode).
Uncheck the checkbox means the connection type you select
above will apply the authentication methods and security
methods in the general settings.
Netbios Naming Packet -
Pass – Click it to have an inquiry for data transmission

between the hosts located on both sides of VPN Tunnel
while connecting.
Block – When there is conflict occurred between the

hosts on both sides of VPN Tunnel in connecting, such
function can block data transmission of Netbios Naming
Packet inside the tunnel.
Multicast via VPN - Some programs might send multicast
packets via VPN connection.
Pass – Click this button to let multicast packets pass

through the router.
 Block – This is default setting. Click this button to let
multicast packets be blocked by the router.
User Name - This field is applicable when you select PPTP or
L2TP with or without IPsec policy above. The length of the
name is limited to 23 characters.
Password - This field is applicable when you select PPTP or
L2TP with or without IPsec policy above. The length of the
password is limited to 19 characters.
Enable Mobile One-Time Passwords (mOTP) - Check this
box to make the authentication with mOTP function.
PIN Code – Type the code for authentication (e.g, 1234).
Secret – Use the 32 digit-secret number generated by mOTP
in the mobile phone (e.g., e759bb6f0e94c7ab4fe6).
Chose one of the subnet selections for such VPN profile.
Assign Static IP Address – Please type a static IP address for
the subnet you specified.
This group of fields is applicable for IPsec Tunnels and L2TP
with IPsec Policy when you specify the IP address of the
remote node. The only exception is Digital Signature (X.509)
