2.5 Communications

2.5.1 Terminal Communications

The terminal utilises the Telstra GPRS network. An authorised SIM card is required to
process transactions on the terminal via the GPRS network. Westpac will provide data only
SIM cards with the terminal.

2.5.2 GPRS Coverage

The GPRS network provides coverage to 96% of Australia's population. To verify if your
terminal has sufficient coverage check the bars on the bottom left of the display screen.
Three ascending bars indicate good signal strength.
3
2
6
5

2.6 Printer and Paper Load Function

9
8
#
0
The EFTPOS Professional Mobile terminal has an in-built thermal printer. To load paper:
(a) Open the paper compartment cover by pressing the sides of the paper compartment
cover and lifting upwards.
Printer Cover
EFTPOS PROFESSIONAL MOBILE GPRS USER GUIDE
1 3
2
4 6
5
7 9
8
*
#
0
5
GETTING STARTED
